Fujitsu PRIMERGY RX200 S6 - Removing a Defective Memory Module; Installing a New Memory Module

108 Operating Manual RX200 S6
CSS components
8.2.2.3 Removing a defective memory module
Figure 31: Removing a memory module
Ê Press the holders on either side of the mounting location concerned outward
(1).
Ê Pull the defective memory module out of the slot (2).
8.2.2.4 Installing a new memory module
V CAUTION!
Please note the equipping rules in the technical manual for the system
board D3031.
Figure 32: Inserting a memory module
Ê Carefully press the memory module into the slot (1) until the fastening tabs
on both sides of it engage (2).
Pay attention to the plug coding.
/
/
