Fujitsu PRIMERGY RX200 S6 - Starting Up and Operation; 5.1 Controls and indicators

RX200 S6 Operating Manual 61
5 Starting up and operation
V CAUTION!
Please note the safety instructions in chapter "Important information" on
page 29.
5.1 Controls and indicators
5.1.1 Front of server
Figure 12: Controls and indicators on the front
1 CPU error indicator 9 ID indicator
2 Memory error indicator 10 Power-on indicator
3 PCI error indicator 11 On/Off button
4 Fan error indicator 12 ID button
5 CSS indicator 13 NMI button
6 Global Error indicator 14 Open/close optical drive
7 Hard disk activity indicator 15 optical drive activity indicator
8 Reset button 16 ID card
햲
햽
햳 햴 햵 햶 햷 햸 햹 햺 햻
햾햿헁 헀
헂
