RX200 S6 Operating Manual 23
Preface
1.5 Technical data
Electrical data (hot-plug power supply unit)
Rated voltage range 100 V - 127 V ⁄ 200 V - 240 V
Frequency 50 Hz - 60 Hz
Max. rated current (770W PSU) 100 V - 240 V / 10 A - 5 A
Max. rated current (450W PSU) 100 V - 240 V / 8 A - 4 A
Effective power 549 W
Apparent power 557 VA
Heat dissipation 1976 kJ/h (1873 btu/h)
Main power fuse 16 A
Protection class I
