66 Operating Manual RX200 S6
Starting up and operation
5.1.2 Rear of server
CSS, Global Error and ID indicators
Figure 14: ID/CSS/Global Error indicator
1 Global Error/CSS/ID indicator
Global Error indicator (orange)
– Lights up orange if a prefailure event has been detected that
requires (precautionary) service intervention.
– Flashes orange if an error was detected that requires service
intervention.
– Does not light up if there is no critical event.
If the event is still acute after a power failure, the indicator is
activated after the restart.
The indicator also lights up in standby mode.
You can find more details on the indicated errors in the System
Event Log (SEL), on the ServerView Local Service Display, in the
ServerView Operations Manager or via the iRMC S2's Web
interface.
