116 Operating Manual RX200 S6
Appendix: server specification
Interfaces
Onboard or integrated controllers
USB connectors 7 x USB 2.0 (3x front, 3x rear, 1x internal)
Graphics (15-pin) 2 x VGA (1x front)
Serial 1 x serial RS-232-C, usable for iRMC S2 or system
or shared
LAN / Ethernet (RJ-45) 2 x Gbit/s Ethernet
Management LAN
(RJ45)
1 x dedicated management LAN connector for iRMC
S2 (10/100 Mbit/s); managment LAN traffic can be
switched to shared onboard Gbit LAN port
RAID Controller Modular RAID 0/1 controller with "Integrated
Mirroring Enhanced" (SAS IME) for SAS1.0.
RAID levels 0, 1 and 1E are supported for internal
hard disk drive configurations. For the Japanese
market only RAID level 1 is supported for internal
hard disk drive configurations.
Modular RAID 0/1 controller with “MegaRAID
functionality” (SAS MegaRAID) for SAS1.0 and
SAS2.0. RAID levels 0, 1,10 and 1E are supported
for internal hard disk drive configurations.
Modular RAID 5/6 controller with "MegaRAID
functionality" (SAS MegaRAID) for SAS1.0 and
SAS2.0. RAID levels 0, 1, 10, 1E, 5, 50, 6 and 60 are
supported for internal hard disk drive configurations.
SATA Controller ICH10R, 4-port for RAID 0,1, 10 (for 4x 2.5-inch
HDDs only) , 1 x SATA channel for DVD
Remote Management
Controller
Integrated Remote Management Controller
(iRMC S2, 32 MB attached memory incl. graphics
controller), IPMI 2.0 compatible
Trusted Platform
Module (TPM)
Infineon / separate module; TCG V1.2 compliant
(option)
