RX2520 M5 Operating Manual 15
3 Product description
This section provides an overview of the server and information on the features
of the PRIMERGY RX2520 M5 server.
The PRIMERGY RX2520 M5 server is available as a rack model.
3.1 Overview of the server
3.1.1 Server front
3.1.1.1 3.5-inch HDD versions
Figure 1: Front side 3.5-inch HDDs (up to 8 HDDs)
Figure 2: Front side 3.5-inch HDDs (up to 12 HDDs)
Pos. Component
1ID card
2 Front panel module
3 ODD (option) / dummy cover
4 Bays for HDDs (depending on the configuration)
5 Front panel on QRL
