Fujitsu PRIMERGY RX2520 M5

28 Operating Manual RX2520 M5
Product description
3.3.2.2 Indicators on the front panel
Figure 10: Indicators on the front panel module
Figure 11: Indicators on the front panel on QRL
Pos. Label Indicator Status Description
1ID
ID
indicator,
see also
"iRMC-
related
status
signals" on
page 30
blue on
The server has been highlighted
using ServerView Operations
Manager, iRMC web interface or the
ID button on the front panel for easy
identification.
flashing
blue
The server has been highlighted for
easy identification using the iRMC
with disabled local VGA output.
