RX2520 M5 Operating Manual 89
8 Technical data
This section explains the specifications for the server. The specifications for this
server are liable to be updated without any notice. Please be forewarned.
I The data sheets for this server contain more technical data. The data
sheets are available online at:
http://www.fujitsu.com/fts/products/computing/servers/primergy
For more information, see the Documents tab under e.g. Rack Servers.
For Japan:
http://www.fujitsu.com/jp/products/computing/servers/primergy
System Board
Processor (CPU)
Memory Modules Configuration
System board type D3386
Chipset Intel
®
C624 series
CPU quantity and type 1 or 2 Intel® Xeon® CPUs (Gold, Silver, Bronze)
Memory slots 12 (6 DIMMs per CPU, 6 channels with 1 slots per
channel)
Memory slot type RDIMM/LRDIMM (DDR4)
Memory capacity
(min. - max.)
8 GB - 384 GB
Memory protection ECC; SDDC; Memory Scrubbing; Memory Mirroring
support
Memory notes 2933 MHz memory modules with 8, 16, 32, 64, 128,
or 256 GB
