Fujitsu PRIMERGY RX2520 M5

16 Operating Manual RX2520 M5
Product description
3.1.1.2 2.5-inch HDD/SSD versions
Figure 3: Front side 2.5-inch HDDs/SSDs (up to 16 HDDs/SSDs)
Figure 4: Front side 2.5-inch HDDs/SSDs (up to 24 HDDs/SSDs)
Pos. Component
1 Front panel module
2ID card
3 ODD (option) / dummy cover
4 Bay for LTO/RDX drive (option)
5 Bays for HDDs/SSDs (depending on the configuration)
6 Front panel on QRL
