Fujitsu PRIMERGY RX2520 M5 User Manual

RX2520 M5 Operating Manual
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.1 Notational conventions . . . . . . . . . . . . . . . . . . . . . 9
2 Before you start . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1 Documentation overview . . . . . . . . . . . . . . . . . . . 11
3 Product description . . . . . . . . . . . . . . . . . . . . . . 15
3.1 Overview of the server . . . . . . . . . . . . . . . . . . . . . 15
3.1.1 Server front . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.1.1.1 3.5-inch HDD versions . . . . . . . . . . . . . . . . . . . . 15
3.1.1.2 2.5-inch HDD/SSD versions . . . . . . . . . . . . . . . . . 16
3.2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.3 Connectors, controls and indicators . . . . . . . . . . . . . 24
3.3.1 Connectors on the server . . . . . . . . . . . . . . . . . . . . 24
3.3.1.1 Server front . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.3.1.2 Server rear . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.3.2 Controls and indicators on the server front . . . . . . . . . . . 26
3.3.2.1 Controls on the front panel . . . . . . . . . . . . . . . . . . 26
3.3.2.2 Indicators on the front panel . . . . . . . . . . . . . . . . . 28
3.3.2.3 Indicator on the ODD . . . . . . . . . . . . . . . . . . . . . 31
3.3.2.4 Indicators on the hot-plug HDD/SSD module . . . . . . . . 32
3.3.3 Indicators on the server rear . . . . . . . . . . . . . . . . . . . 33
3.3.3.1 Indicators on the I/O panel . . . . . . . . . . . . . . . . . . 33
3.3.3.2 Indicator on hot-plug PSU . . . . . . . . . . . . . . . . . . 37
4 Important information . . . . . . . . . . . . . . . . . . . . . 39
4.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 39
4.2 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . 47
4.3 ENERGY STAR . . . . . . . . . . . . . . . . . . . . . . . . . 48
4.4 FCC Class A Compliance Statement . . . . . . . . . . . . . 48

Fujitsu PRIMERGY RX2520 M5 Specifications

General

Tcase	72 °C
Scalability	4S
Processor cache	16.5 MB
Processor cores	4
Processor model	5222
System bus rate	- GT/s
Processor socket	LGA 3647 (Socket P)
Processor threads	8
Processor codename	Cascade Lake
Execute Disable Bit	Yes
Motherboard chipset	Intel® C624
Processor frequency	3.8 GHz
Processor cache type	L3
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	76.0 x 56.5 mm
Processor boost frequency	3.9 GHz
Processor operating modes	64-bit
Embedded options available	No
Supported instruction sets	AVX-512
Thermal Design Power (TDP)	105 W
Number of processors installed	1
Maximum number of SMP processors	2
Maximum number of PCI Express lanes	48
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2933 MHz
Maximum internal memory supported by processor	1024 GB
HDD size	- \
RAID levels	0, 1
HDD interface	-
Supported HDD sizes	2.5 \
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Chassis type	Rack (2U)
Trusted Platform Module (TPM) version	2.0
Compatible operating systems	Microsoft Hyper-V Server 2016 Microsoft Windows Server 2016 Datacenter Microsoft Windows Server 2016 Standard Microsoft Windows Server 2016 Essentials Microsoft Windows Storage Server 2016 Standard Microsoft Hyper-V Server 2012 R2 Microsoft Windows Server 2012 R2 Datacenter Microsoft Windows Server 2012 R2 Standard Microsoft Windows Server 2012 R2 Essentials Microsoft Windows Storage Server 2012 R2 Standard VMware vSphere 6.5 VMware vSphere 6.0 SUSE Linux Enterprise Server 12 Red Hat Enterprise Linux 7 Red Hat Enterprise Linux 6 Univention Corporate Server 4
Memory slots	12
Internal memory	32 GB
Maximum internal memory	768 GB
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
Power supply	800 W
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 85 %
Certification	CB, RoHS, WEEE, GS, CE, CSAc/us, FCC Class A, ICES-003/NMB-003 Class A, VCCI:V3 Class A + JIS 61000-3-2, EAC, KC, CCC, RCM, BSMI
PCI Express slots version	3.0
PCI Express x16 (Gen 3.x) slots	3
On-board graphics card model	Not available
Processor ARK ID	192445

Weight and Dimensions

Depth	770 mm
Width	482.4 mm
Height	86.6 mm
Weight	25000 g
