Fujitsu PRIMERGY RX2520 M5

92 Operating Manual RX2520 M5
Technical data
Slots
Drive bays
Operating Panel
PCI-Express -
Gen3 x16
3 x low profile
PCI-Express - Gen3 x8 3 x low profile
Slot notes CPU1 supports three slots PCIe Gen3 x8 and one
slot PCIe Gen3 x16.
One PCIe Gen3 x8 slot can be occupied with a
Modular RAID controller.
CPU2 supports two slots PCIe Gen3 x16.
HDD bay configuration 4x 3.5-inch, 8x3.5-inch, 12x 3.5-inch for SAS/SATA
8x 2.5-inch, 16x2.5-inch, 24x 2.5-inch for SAS/SATA
Accessible drive bays
1 x 5.25/0.5-inch for ODD
Notes accessible drives all possible options described in relevant system
configurator
Operating buttons On/Off button
ID button
Reset button
NMI button
Status LEDs Global Error indicator (orange)
ID indicator (blue)
HDD/SSD activity indicator (green)
Power-on indicator (green)
AC connected indicator (green)
CSS indicator (orange)
Status LED at
system rear side
Global error / CSS / ID indicator (orange / orange / blue)
LAN connection indicator (green)
LAN speed indicator (green/yellow)
