TX200 S5 Options Guide 21
4 Preparation
V CAUTION!
Follow the safety instructions in the chapter “Safety instructions”.
4.1 Floorstand model
4.1.1 Opening the server
Ê Terminate all applications and shut down the server correctly.
Ê If your operating system has not switched off the server, press the on/off
button.
Ê Pull all power connectors out of the power outlets.
Ê Unlock the server and remove the key.
Figure 2: Opening the server
Ê Pull the locking lever as far as it will go (1). This pushes the side cover
backward (2).
Ê Remove the side cover (3).
/
0
1
