TX200 S5 Options Guide 33
Main memory Expanding the main memory
5.2 Expanding the main memory
Ê Open the server and remove system fan 2 (or 2&4) as described in the
chapter “Preparation”.
Ê Press the holders on either side of the mounting location concerned
outward.
Figure 14: Expanding the memory module
Ê Carefully press the memory module into the slot (1) until the fastening tabs
on both sides of it engage (2).
Ê Reinstall system fan 2 (or 2&4) as described in the chapter “Completion”.
Ê Close the server, connect it to the power outlet, and switch it on as described
in the chapter “Completion”.
Ԙ
ԙ
ԙ
