TX200 S5 Options Guide 75
Further options USB Flash Module (UFM)
Ê Reinstall system fan 2 (or 2&4) as described in the chapter “Completion”.
Ê Close the server, connect it to the power outlet, and switch it on as described
in the chapter “Completion”.
I You can find information on configuring the TPM in the "BIOS Setup
Utility" manual.
9.2 USB Flash Module (UFM)
The server can be equipped with a USB Flash Module (UFM). Connect the UFM
to the system board so that the spacer clicks into place.
This module can be used as optional memory for software (e.g. VMware) or as
a software dongle.
Figure 63: UFM installation kit
Ê Open the server as described in the chapter “Preparation”.
1 USB Flash Module (UFM) 3 UFM spacer
2 UFM nylon screw
Ԙ
ԙ
Ԛ
