Fujitsu PRIMERGY TX200 S5

TX200 S5 Options Guide 25
Preparation Rack model
4.2.2 Removing the rack front cover
You remove the rack front cover when making the following expansions:
– Installing/removing accessible drives
Figure 6: Removing the rack front cover
Ê Remove two knurled screws on either side (1).
Ê Remove the rack front cover to the front together with the plastic cover (2).
Ԙ
ԙ
Ԙ
