30 Options Guide TX200 S5
Equipping rules Main memory
5.1 Equipping rules
Figure 11: Configuration of the main memory - photo
Figure 12: Configuration of the main memory - diagram
DIMM1F
DIMM2F
DIMM1E
DIMM2E
DIMM1D
DIMM2D
DIMM2A
DIMM1A
DIMM2B
DIMM1B
DIMM2C
DIMM1C
CPU 1
CPU 2
