Fujitsu ScanSnap SV600

How to Place Documents
When you place down documents, use the Background Pad.
If you scan documents without using the Background Pad, the document edges may not be detected
correctly and the created scanned image may be different from the document.
For details about documents that can be scanned with the ScanSnap, refer to "Documents to Scan"
(page 51).
l "Scan Area" (page 52)
l "When Placing a Standard Size Document" (page 53)
l "When Placing a Book" (page 53)
l "When Placing Multiple Documents at Once" (page 53)
Scan Area
Place a document with the scanned side face-up in the following scan area.
Use the following to determine the scan area.
l Area: Reference marks of the Background Pad
l Height: Lines on the base of the ScanSnap
30 mm (1.18 in.)
Line
5 mm (0.2 in.)
300 mm (11.81 in.)
400 mm
432 mm
(15.75 in.)
(17.01 in.)
ATTENTION
If a document is placed outside of the scan area, part of the scanned image may be left out or blurred.
How to Place Documents
52
