19.PARAMETER TABLE
1.7.3.x.2 Temperature for actuation:
Temperature of the dry bulb sensor to actuate the output.
1.7.3.x.3 Temperature for shutdown:
Temperature of the external temperature sensor (TBS) for shutting down the output.
1.7.3.x.4 Differential for actuation:
Value of the difference between dry and wet bulb temperatures for actuating the output.
1.7.3.x.5 Differential for shutdown:
Value of the difference between dry and wet bulb temperatures for shutting down the output.
1.7.3.x.6 Minimum operating temperature (TBS):
Minimum ambient temperature for adiabatic condensation operation for differential control.
1.7.3.x.7 Differential validation time:
Maximum time to reach the shutdown differential (1.7.3.x.4).
1.7.3.x.8 Time for next attempt:
Time that the control waits before actuating the output for a new attempt to reach the shutdown differential
1.7.3.x.9 Wet bulb temperature sensor (TBS):
Specifies the wet bulb temperature sensor.
1.7.3.x.10 Digital output:
Digital output address
1.7.3.x.11 Time on:
Time length the output remains on in Cycle Timer Mode and Temperature with cycle timer.
1.7.3.x.12 Time off:
Time length the output remains off in Cycle Timer Mode and Temperature with cycle timer.
1.7.3.x.14 Start time:
Logic operating start time.
1.7.3.x.15 End time:
Logic operating end time.
1.7.4.1 Floating condensation:
The letter x represents discharges 1 to 3.
1.7.4.x.1 Fluctuation start temperature:
Temperature value for starting control of the discharge setpoint. Floating condensation operates below this value.
1.7.4.x.2 Minimum safety setpoint:
Minimum value of the pressure setpoint for the discharge.
0 = Not configured
Sensor options:
1 = Base - S1
2 = Base - S2
3 = Base - S3
5 = Base - S5
4 = Base - S4
6 = Base - S6
0 = Not configured
Sensor addresses:
1 = Base - O1
2 = Base - O2
3 = Base - O3
5 = Base - O5
4 = Base - O4
6 = Base - O6
Feature
Minimum
Maximum Unit
Standard
Description
1.7.4.x.1
1.7.4.x.2
1.7.4.x.3
1.7.4.x.4
00:00 [off] 24:00 [off]0
°C (F)
Psi (Bar)
°C (F)
min
min
00:00 [off] 24:00 [off]
0 (0)
1.7.4.x.5
0
-50,1 [off] (-58,2)
-14,7 (-1,0)
-50,1 [off] (-58,2)
250,0 (17,2)
1,0 (1,8)
200,0 (392,2)
850,0 (58,6)
200,0 (360,0)
Fluctuation start temperature
Minimum safety setpoint
Safety subcooling
Start time
End time
Note: If parameters 1.7.3.x.13 and 1.7.3.x.14 are set to OFF, the
adiabatic condensation will remain active.
Note: The sensors present in the expansion modules will be listed in
menu 4 after their configuration.
