19.PARAMETER TABLE
1.7.2.x Compressor protection thermostat:
The letter x represents compressors 1 to 6 for each suction line
Suction 1: x between 1 and 6.
Suction 2: x between 7 and 12.
Suction 3: x between 13 and 18.
1.7.2.x.1 Output control temperature:
Control temperature value for actuating the cooling output.
1.7.2.x.2 Compressor shutdown temperature:
Temperature value for compressor shutdown and alarm indication.
1.7.2.x.3 Hysteresis:
It is the temperature range for controlling the fans linked with the digital outputs. This pressure value is related to the setpoint that defines the actuation
points for each fan (actuation interval = setpoint + hysteresis).
1.7.2.x.4 Temperature sensor:
Address of the temperature sensor that measures the temperature of the compressor.
1.7.2.x.5 Digital output:
Digital output address controlled by the protection thermostat.
1.7.3.x Adiabatic Condensation:
The letter x represents discharges 1 to 3.
1.7.3.x.1 Control mode:
Configures the operation mode according to:
0 = Not configured
1 = Base - S1
2 = Base - S2
3 = Base - S3
4 = Base - S4
5 = Base - S5
6 = Base - S6
Minimum
Maximum Unit
Standard
Description
Compressor shutdown temperature
Temperature sensor
Output control temperature
Hysteresis
Digital output
10,0 (18,0)
- -
- -
200,1 [off] (392,2)
200,1 [off] (392,2)
200,1 [off] (392,2)
200,1 [off] (392,2)
5,0 (9)
0
0
0,1 (0,2)
0
0
0 (32,0)
0 (32,0)
°C (F)
°C (F)
°C (F)
Feature
1.7.2.x.1
1.7.2.x.2
1.7.2.x.3
1.7.2.x.5
1.7.2.x.4
Feature
Minimum
Maximum Unit
Standard
Description
1.7.3.x.1
1.7.3.x.2
1.7.3.x.3
1.7.3.x.4
200,1 [off] (392,2) -50,1 (-52,2)
25,1 (45,2)
-50,1 (-58,2)
0 (0) 0 (0)
°C (F)
-
°C (F)
°C (F)
°C (F)
°C (F)
25,1 (45,2) 25,1 (45,2)0 (0)
-
-
min
min
min
min
min
hours: min
min
hours: min
1.7.3.x.5
1.7.3.x.9
1.7.3.x.6
1.7.3.x.10
1.7.3.x.7
1.7.3.x.11
1.7.3.x.13
1.7.3.x.8
1.7.3.x.12
1.7.3.x.14
Temperature for actuation
Minimum operating temperature (TBS)
Differential for actuation
Time for next attempt
Time on
Digital output
Start time
Control mode
Differential for shutdown
Temperature for shutdown
Differential validation time
Wet bulb temperature sensor (TBU)
Time off
End time
0
-50,0 (-58,0)
1
1
0
0
1
0
1
0
0
18,0 (64,4)
30
30
0
0
3
200,0 (392,0)
999
999
-
-
999
999
1440 [off]
1440 [off]
5
5
1440 [off]
1440 [off]
-50,1 (-58,2) -50,1 (-52,2)200,1 (392,2)
0 = Not configured
1 = Base - O1
2 = Base - O2
3 = Base - O3
4 = Base - O4
5 = Base - O5
6 = Base - O6
0 = Off
1 = By temperature
2 = Cycle timer
3 = Temperature with cycle timer
Note: The sensors present in the expansion modules will be listed in
menu 4 after their configuration.
Note: The outputs present in the expansion modules will be listed in
menu 4 after their configuration.
63
