FULTON VSRT-60 - Multi Bloc Gas Valves

INSTALLATION - 2
Fulton Ltd
2.5.2 MULTI BLOC GAS VALVES
Note: See attached manufacturers leaflets.
Output pressure
cont
roller adjusting screw
Hydraulic Brake
Op
erating indicator
Main gas flow adjustment
Adj
ustable pressure
switch
Test point connection
Test
point connection
downstream of Valve 1
Gas output flange
Ga
s input filter cover
Test point connection
dow
nstream of Valve 2
Test point connection
upst
ream of Valve 1
Figure. 9 - Pilot Line Gas Valve
PRE-MI
X (GAS & AIR) ACTUATOR
Servo motor body
Valve coupling
GAS GOVERNOR &
VALVE
Gas valve
Gas governor
Electrical connections
Low gas pressure switch
Gas out fla
nge
Gas in flange
Filter & main housing
Fi
lter caps
Figure. 10 -
Main Gas Valve (Siemens)
