5. VIDEO PLOTTER OPERATION
5-3
[MARK MENU]
1 ORIGIN MARK STAB
GND/SEA
2 MARK KIND
ORIGIN MARK(No.)/
ORIGIN MARK(SYM)/
MAP MARK/
WP 1~50/
WP 51~100/
WP 101~150/
WP 151~198/
OWN SHIP SHAPE
9 MAP DISPLAY
OFF/ON
0 MAP MARK COLOR*
RED/GRN/BLU/YEL
CYA/MAG/WHT
5.4 Radar Map
A radar map is a combination of map lines and symbols whereby the user can
define and input the navigation data, route planning and monitoring data.
The radar map may contain 3,000 points of data. The map data can be
memorized to facilitate repeated use on a routine navigation area.
The user can create a radar map on-real time while using the radar for
navigation or at leisure time at anchor or while the radar is not being used. Place
of a map can be made for any waterways apart from the actual own ship
location.
The radar map feature is available with the non-IMO radar. All radar map
functions are accessed from the radar display. To choose the radar display, use
the trackball to choose the DISPLAY MODE box and push the left button to
display “RADAR.” Then, follow the procedures in this section to create a radar
map.
5.4.1 Turning on the radar map display
1. Roll the trackball to choose the MARK box.
2. Push the right button to open the MARK menu.
MARK menu
3. Roll the wheel to choose 9 MAP DISPLAY and then push the wheel.
4. Roll the wheel to choose ON and then push the wheel or the left button.
5. Push the right button to close the menu.
*: NOT available
on IMO radar.
