1. Menu Tree
Main menu (accessed by MENU key or MENU box)
1 ECHO
2 MARK
3 ALARM
(Continued on next page)
1 BACK
2 2ND ECHO REJ (OFF, ON)
3 TUNE INITIALIZE
4 PM (OFF, ON)
5 SART (OFF, ON)
6 WIPER (OFF, 1, 2)
1 BACK
2 OWN SHIP MARK (OFF, ON)
3 STERN MARK (OFF, ON)
4 INDEX LINE BEARING (REL, TRUE)
5 INDEX LINE (1, 2, 3, 6)
6 INDEX LINE MODE (VERTICAL, HORIZONTAL)*
8 EBL OFFSET BASE (STAB GND, STAB HDG, STAB NORTH)
9 EBL CURSOR BEARING (REL, TRUE)
0 RING (OFF, ON)
1 BACK
2 TARGET ALARM MODE (IN, OUT)
3 TARGET ALARM LEVEL (1, 2, 3, 4)
4 WATCH ALARM (OFF, 6M, 10M, 12M, 15M, 20M)
5 ALARM SOUND LEVEL (LOW, MID, HIGH)
6 [ALARM OUT1]
7 [ALARM OUT2]
8 [ALARM OUT3]
9 AUDIO ALARM
(OFF, ON)
MENU key
or
MENU box
1 BACK
2 (TARGET ALARM, WATCH ALARM,
GUARD ZONE, LOST TARGET, CPA
LIMIT, AUTO ACQ TARGET FULL,
MAN ACQ TARGET FULL, ARP
SYSTEM ERROR, AZIMUTH, HEAD
LINE, TRIGGER, VIDEO, GYRO, LOG
EPFS, XTE, ARRIVAL WPT, DEPTH,
ALARM ACK OUT)
* Appears when
5 INDEX LINE
is set for other
than "1".
