5. VIDEO PLOTTER OPERATION
5-11
[PLOTTER]
1 BACK
2 CHART COLOR*
GRN/YEL/CYA
ORANGE/GRAY
3 OWN TRACK INTERVAL
OFF/10S/30S/
1M/2M/3M/6M
4 OWN TRACK COLOR
RED/GRN/BLU/YEL/
CYA/MAG/WHT
5 TGT TRACK INTERVAL*
10S/30S/1M/
2 M/3M/6M
6 TGT TRACK COLOR*
RED/GRN/BLU/YEL/
CYA/MAG/WHT
7 CURSOR L/L ALIGN
OFF/ON
8 [DATA ERASE]
9 [DISPLAY]
4. Roll the wheel to choose ON and then push the wheel or the left button.
“ALIGN” appears (in red) next to cursor position in the cursor data box. (To
remove the correction, choose OFF. If you are using the AIS function, choose
ON.)
5. Push the right button twice to close the menu.
5.7.4 Chart land color
You may choose the color for the land on charts as follows:
1. Roll the trackball to choose the MENU box at the right side of the screen and
then push the left button.
2. Roll the wheel to choose 5 PLOTTER and then push the left button.
PLOTTER menu
3. Roll the wheel to choose 2 CHART COLOR and then push the left button or
the wheel.
4. Choose color desired and push the wheel or the left button.
5. Push the right button twice to close the menu.
*: Not available
on IMO radar.
