1. RADAR OPERATION
1-10
[CURSOR MENU]
2 ↓
TARGET DATA & ACQ/
TARGET CANCEL/
ACQ/
REF MARK/
EBL OFFSET/
OFFCENTER
ZOOM/
MARK DELETE/
CHART ALIGN
8 ↑
1.6 Cursor Menu
Functions which require the use of the cursor, such as EBL offset and zoom,
may be activated directly from the guidance box or from the CURSOR menu,
either method with the cursor inside the effective display area. Below is the
procedure for choosing a cursor-related function from the CURSOR menu. In
later sections only the procedure for selection from the guidance box is given.
1. Roll the trackball to place the cursor inside the effective display area.
2. Roll the wheel to show “TARGET DATA & ACQ / CURSOR MENU” in the
guidance box.
3. Push the right button to show the CURSOR menu.
CURSOR menu
4. Roll the wheel to choose “2” and then push the wheel or the left button.
5. Roll the wheel to choose function desired and then push the wheel or the left
button.
Note: For operation from the keyboard, you may press the [2] key to choose
a function in top-to-bottom order or the [8] key to choose in reverse
order.
Cursor Menu item Description
TARGET DATA & ACQ ARP: Acquires ARP target; displays data for chosen ARP
target.
AIS: Activates sleeping AIS target; display data for chosen
AIS target.
TARGET CANCEL ARP: Cancels tracking on chosen ARP target.
AIS: Sleeps chosen AIS target.
ACQ ARP: Acquires chosen echo.
AIS: Activates chosen AIS target.
REF MARK Inscribes reference mark, for target-based speed input.
EBL OFFSET Offsets EBL, to measure range and bearing between two
targets.
OFF CENTER Shifts screen center to chosen location.
ZOOM Zooms chosen location.
MARK DELETE Deletes chosen mark (plotter mark, origin mark or
waypoint mark).
CHART ALIGN Aligns chart with radar picture.
