1. RADAR OPERATION
1-63
Picture setup options and default settings
1 INT
REJECT
2 ECHO
STRETCH
3 ECHO
AVERAGE
4 NOISE
REJ
5 AUTO
STC
6 AUTO
RAIN
7 VIDEO
CONTRAST
PICTURE 1 2 OFF OFF OFF OFF OFF 2-B
PICTURE 2 2 2 1 OFF OFF OFF 3-B
PICTURE 3 2 OFF 2 OFF ON OFF 2-B
PICTURE 4 2 OFF OFF OFF OFF 2 2-A
NEAR 2 OFF OFF OFF OFF OFF 3-B
FAR 2 2 3 OFF ON OFF 3-C
NEAR BUOY 2 1 1 OFF OFF OFF 3-B
FAR BUOY 2 2 3 OFF ON OFF 3-C
ROUGH SEA 2 OFF 2 OFF ON OFF 2-A
SHIP 3 2 OFF OFF OFF OFF 3-C
HARBOR 2 OFF OFF OFF OFF OFF 3-B
COAST 2 OFF OFF OFF OFF OFF 3-B
8 PULSE 9 CONDITION
P/L on
0.5 nm
P/L on
0.75 nm
P/L on
1.5 nm
P/L on 3
nm
P/L on 6
nm
P/L on
12-24 nm
Sea Cond. STC Range
PICTURE 1 S1 S1 S2 M1 M2 L 2 ±0
PICTURE 2 S1 S1 M1 M2 M3 L 2 ±0
PICTURE 3 S1 S1 S2 M1 M2 L 3 ±0
PICTURE 4 S1 S1 S2 M1 M2 L 2 ±0
NEAR S1 S1 S2 M1 M2 L 2 ±0
FAR S1 S1 M1 M3 L L 3 ±0
NEAR BUOY S1 S1 M1 M2 L L 2 ±0
FAR BUOY S1 S1 M1 M3 L L 3 ±0
ROUGH SEA S1 S1 S2 M1 M2 M3 4 ±0
SHIP S1 S1 M1 M2 M3 L 2 ±0
HARBOR S1 S1 S2 M1 M3 L 2 ±0
COAST S1 S1 M1 M2 M3 L 2 ±0
1.33.1 Choosing a picture setup option
You may choose a picture setup options as follows:
1. Roll the trackball to choose the PICTURE box at the left side of the screen.
NEAR BUOY*
4
* Other indications:
NEAR, FAR, NEAR BUOY,
FAR BUOY, ROUGH SEA,
SHIP, HARBOR, COAST,
PICTURE 1 - PICTURE 4
PICTURE box
2. Push the left button to choose picture setup option desired.
