APPENDIX
AP-2
4 ARP
z
AIS
5 PLOTTER
1 BACK
2 GUARD ZONE STAB (STAB HDG, STAB NORTH)
3 GUARD POLYGON (OFF, STAB GND, STAB HDG, STAB NORTH)
4 [TRIAL MANEUVER]
5 [ARP SYMBOL]
6 [AIS SYMBOL]
7 [FUSION]
8 AIS FUNCTION (OFF, ON)
1 BACK
2 TRIAL (OFF, STATIC, DYNAMIC)
3 TRIAL SPEED RATE (0.0 kt, 0.00 °/s, two sets)
4 TRIAL TURN RATE (0.0 kt, 0.00 °/s, two sets)
1 BACK
2 ARP SYMBOL COLOR (RED*, GRN, BLU, YEL,
CYA, MAG, WHT)
3 ARP SYMBOL SIZE (SMALL, STD, LARGE)
4 PAST POSN COLOR (RED, GRN, BLU,
YEL, CYA, MAG, WHT)
5 PAST POSN POINTS (5, 10)
1 BACK
2 AIS SYMBOL COLOR (RED*, GRN, BLU, YEL,
CYA, MAG, WHT)
3 AIS SYMBOL SIZE (SMALL, STD, LARGE)
4 ROT TAG LIMIT (000.1- 720.0°/min)
5 PAST POSN COLOR (RED, GRN, BLU,
YEL, CYA, MAG, WHT)
6 PAST POSN POINTS (5, 10)
1 BACK
2 FUSION TARGET (OFF/ON)
3 GAP (0.000 - 0.999 (nm))
4 RANGE (0.000 - 0.999 (nm))
5 BEARING (0 - 9.9°)
6 SPEED (0.0 - 9.9 (kt))
7 COURSE (0 - 9.9°)
1 BACK
2 CHART COLOR (GRN, YEL, CYAN, ORANGE, GRAY)*
3 OWN TRACK INTERVAL (OFF, 10S, 30S, 1M, 2M, 3M, 6M)
4 OWN TRACK COLOR (RED, GRN, BLU, YEL, CYA, MAG, WHT)
5 TGT TRACK INTERVAL (10S, 30S, 1M, 2, 3M, 6M)*
6 TGT TRACK COLOR (RED, GRN, BLU, YEL, CYA, MAG, WHT)*
7 CURSOR L/L ALIGN (OFF, ON)
8 [DATA ERASE]
1 BACK
2 OWN TRACK (30%/50%/80%/ALL)
3 TARGET TRACK (30%/50%/80%/ALL)*
4 MARK ALL ERASE
5 WPT ALL ERASE
6 NAV LINE ALL ERASE
(Continued on next page)
(Continued from previous page)
*: Not available on
IMO-type radar.
