APPENDIX
A
P-7
[BRILL1 MENU (2/2)]
1 BACK
2 BRG CURSOR
3 EBL
4 VRM
5 INDEX LINE
6 ARP SYMBOL
7 AIS SYMBOL
8 L/L GRID
9 MARK
0 CHART*
[BRILL1 MENU (1/2)]
1 ECHO COLOR**
YEL/GRN/
WHT/COLOR*
2 BKGD COLOR**
BLK-GRN/
BLK-RED/
BLU-CIR/
BLU/BRT-BLU
3 PANEL DIMMER
4 CHARACTER
5 CURSOR
6 ECHO
7 TRAIL
8 HL
9 RING
0 NEXT
BRILL menu, page 1
BRILL menu, page 2
[PICTURE MENU]
1 INT REJECT
OFF/1/2/3
2 ECHO STRETCH
OFF/1/2/3
3 ECHO AVERAGE
OFF/1/2/3
4 NOISE REJ
OFF/ON
5 AUTO STC
OFF/ON
6 AUTO RAIN
7 VIDEO CONTRAST
1/2/3/4/
A/B/C
8
[PULSE]
[PULSE MENU]
1 BACK
2 0.5NM
S1/S2
3 0.75NM
S1/S2/M1
4 1.5NM
S1/S2/M1
5 3NM
S2/M1/M2/M3
6 6NM
M1/M2/M3/L
7 12-24NM
M2/M3/L
PICTURE menu
OFF/1/2/3/4
PULSE menu
CONDITION menu
[CONDITION MENU]
1 BACK
2 SEA CONDITION
1/2/3/4/5
3 ANT HEIGHT
5/7.5/10/15/20/25/30/
35/40/45/
more 50 m
4 STC RANGE
+00
* Not available
on IMO radar.
ANTENNA INFORMATION display
[ANT INFORMATION]
ANT NO 1
BAND:X-BAND
MODEL:12 UP
POS :FORE
ANT NO 2
BAND:X-BAND
MODEL:12
POS :MAIN
ANT NO 3
BAND :
MODEL :
POS :
ANT NO 4
BAND :
MODEL :
POS :
OWN RADAR NO.
Note:For default settings for each picture
 setup type see paragraph 1.33.
**: Settings for brilliance sets BRILL2-BRILL4
BRILL2: ECHO COLOR: YEL
BKGD COLOR: BLK-RED
BRILL3: ECHO COLOR: YEL
BKGD COLOR: BLU-CIR
BRILL4: ECHO COLOR: YEL
BKGD COLOR: BLU
MARK menu
[MARK MENU]
1 ORIGIN MARK STAB
GND/SEA
2 MARK KIND
ORIGIN MARK(No.)/
ORIGIN MARK(SYM)/
MAP MARK/
WP 1~50/
WP 51~100/
WP 101~150/
WP 151~198/
OWN SHIP SHAPE
9 MAP DISPLAY
OFF/ON
0 MAP MARK COLOR*
RED/GRN/BLU/YEL/
CYA/MAG/WHT
0 DEFAULT (ENTERX3)
9
[CONDITION]
