Antenna unit RSB-103/104/105 (FAR-2827W)
FURUNO Model FAR-2827W
Unit Antenna Unit RSB-104/105
ELECTRICAL PARTS LIST
SYMBOL NAME REMARKS
PRINTED CIRCUIT BOARD
TB 03P9349
BP GEN 03P9347
MOTOR
D8G-516
2003/10
Transceiver unit RTR-081 (FAR-2827W)
FURUNO Model FAR-2827W
Unit Transceiver Unit RTR-081
ELECTRICAL PARTS LIST
SYMBOL NAME REMARKS
PRINTED CIRCUIT BOARD
TB 03P9349
IF AMP 03P9335
PWR 03P9348
MD 03P9244
RFC 03P9346
MIC ASSEMBLY
RU-9603
MOTOR
24 rpm
TR LIMITER
RU-9290
CIRCULATOR
RC_3686
PULSE TRANSFORMER
RT-9023
MAGNETRON
MG5436
2003/10
