<Before Use>
Receiver R51
14DPS
Ɣ
Antenna
Ɣ
Connectors
Ɣ'*
Ɣ0RQLWRU/('
Ɣ&+
〜
Ɣ'*
Ɣ%&
Connector
"1 through 12": outputs for the channels 1 through 12
"DG1", "DG2": outputs of DG1 and DG2 channels
"B/C": connector for the power and DSC.
LED Monitor
This monitor is used when changing the
frequency of the receiver
.
Receiver nomenclatur
e
Before using the receiver
, be sure to read the precautions listed in the following pages.
