GY701. Separate the pitch signal at the transmit-
ter side, and input this signal to the GY701. To do
that, making the programmable mixing as pitch->
AUX, and input AUX signal to the GY701.
This function is only available at S.Bus connec-
tion. Invalid is displayed at PWM connection.
Pushing data+ or – key, the mode is changed.
(16) F/F mixing rate
default: 0 %
range: -100%
〜
+100%
It adjusts the F/F mixing rate. It can adjust low or
high pitch rate individually from pitch zero point.
Pushing data+ or – key, the value is changed.
(17) F/F mixing acceleration gain
default: 0 %
range: 0
〜
200 %
It sets the F/F mixing acceleration gain. Pushing
data+ or – key, the value is changed.
(18) Pitch zero setting
default: 1520 uS
It sets the pitch zero point of GY701. Move the
pitch stick to the zero pitch, push data+ or – key.
The zero pitch signal is memorized to GY701.
The display shows
！
marked at the setting point.
This setting must be done when F/F mixing is
used.
(19) Pitch low setting
default: 1940 uS
It sets the minimum pitch point of GY701. Move
the pitch stick to minimum pitch, push data+ or
– key. The minimum pitch signal is memorized
to GY701. The display shows
！
marked at the
setting point. This setting must be done when F/F
mixing is used.
(20) Pitch high setting
default: 1100 uS
It sets the maximum pitch point of GY701. Move
the pitch stick to maximum pitch, push data+ or
– key. The maximum pitch signal is memorized
to GY701. The display shows
！
marked at the
setting point. This setting must be done when F/F
mixing is used.
(21) Sensor mode
default: Middle
It selects the response of the gyro sen-
s o r s i g n a l . T h e r e s p o n s e i s o r d e r e d b y
Moderate→Middle→Quick, but the stability is
vice versa. Select the good matching for the heli.
