FXO H.323 Gateway User Manual Document Ver.: 118a
Release Sep, 2004
100
Analizing!! Please wait a moment...
(You could hang up the call from PSTN if you get this message)
Frequency 1 : 473
Frequency 2 (2623) is more than 1000, please ignore it.
0. 25sec on 0.25sec off
tone 4 473 473 8 8 25 25 1023 1023
(Please configure the high and low frequency as the same value if you just
get a singal frequency)
tone –print
Disconnect tone 1 paramter
Frequency high : 620
frequency low : 480
frequency high level : 8
frequency low level : 8
Tone1 on : 25
Tone1 off : 25
Tone2 on : 1023
Tone2 off : 1023
Disconnect tone 2 paramter
Frequency high : 450
frequency low : 0
frequency high level : 8
frequency low level : 0
Tone1 on : 35
Tone1 off : 35
Tone2 on : 1023
Tone2 off : 1023
Disconnect tone 3 paramter
Frequency high : 620
frequency low : 480
frequency high level : 8
