FXO H.323 Gateway User Manual Document Ver.: 118a
Release Sep, 2004
76
-line1 Line 1 E.164 number.
-line2 Line 2 E.164 number.
-line3 Line 3 E.164 number.
-line4 Line 4 E.164 number.
-passwd H.235 security password.
-alias IP side registered H323 ID.
-display String representing display information for reporting
to the called party.
-gkid Gatekeeper ID.
-gkdis Gatekeeper discovery (0=Off, 1=On).
-ttl RAS TTL time (0~3600 second).
-rtp RTP port number (1024~65532).
-gkfind Gatekeeper finding port (1024~65535).
-gkras Gatekeeper RAS port (1024~65535).
-h225 H225 ras port (1024~65535).
-q931 H225 call signal port (1024~65535).
-dstq931 Destination H225 call signal port (1024~65535).
-range Dynamically allocated port range (1024~19999).
-respto Max waiting time for 1st response to a new call (1~200).
-connto Max waiting time for call establishment after receiving 1st
response of a new call (1~20000).
Note:
Range of IP address setting (0.0.0.0 ~ 255.255.255.255).
Example:
h323 -gk 210.59.163.171 -line1 70 -line2 71 -line3 72 -line4 73
h323 -alias Your_Alias_Name -gkid GK -gkdis 1 -passwd 1234
h323 -range start 1024 end 19999 pbook -add name Test ip 210.59.163.202
e164 1001
pbook -insert 3 name Test ip 210.59.163.202 e164 1001
pbook -delete 3
pbook -search ip 192.168.4.99
pbook -modify 3 name Test ip 210.59.163.202 e164 1001
usr/config$
Parameter Usages:
-print print current h323 related settings
