FXO H.323 Gateway User Manual Document Ver.: 118a
Release Sep, 2004
97
Frequency 2 : 474
0.25sec on 0.25sec off
usr/config$
The Procedures of recording the disconnect tone
Before you start ：
Two PSTN lines which connected with the Line 1 and Line 2 port.
Configure Peer-to-Peer mode.
Please record the disconnect tone just follow the stage as below ：
1. Please enter the command before you record the disconnect tone：
record –tone
2. Make a call from PSTN side into Line 2 port.
3. You will get a greeting when the call enter the gateway.
4. Pease dial the number of the Line 1 port.
5. You will get another dial tone from the PSTN line which was connected
with the Line 1 port.
6. Answer the call and make sure the call is connected.
7. Hang up the phone which is from the Line 2 port and you will get the
disconnect tone from the Line 1 port.
8. When you get the disconnect tone from the Line 2 port, press <R> and
<ENTER> buttons to start recording the disconnect tone.
9. Please hang up the phone if you get the message as below：Analizing!!
Please wait a moment…
10. There are three values you will get after analyzing. Please leave the value
which is over 1000 Hz, this is not the frequency of disconnect tone.
11. Please put the frequency in the tone table just follow the command：
tone 4 420 680 8 8 25 25 50 50
【Example-1】
(Make a call from PSTN to FXO port)
usr/config$ record -tone
