G-Tek 27 Series - INSTALLATION

Page No. 10
6.1 INSTALLATION
Figure-3 A
Figure-3 B
Figure 3 Environmental Conditions
Environmental Conditions:
Recorder should be used with proper environmental conditions for better operation. The
environmental conditions are shown in Figure 3.
Attention
Select a location away from strong electrical and magnetic field. If this is not possible,
particularly in application where mobile communication device is expected to be used,
screened cables within earthed (grounded) metal contact must be used as shown in above
figure 3B.
