5.3 TECHNICAL DATA
Table 1 Technical data
Model No
CR2010 Series; BBR Chart Recorder
Product Code*
27x03
Recording System
No. of Pens
1 – Suitable for marking on Pressure Sensitive Paper
Pen Marking
Continuous
Pen Response Time
<5Sec (Full Scale)
Pen Resolution
Stepper Motor Controlled better than 0.1% FSD
Overshoot
None
Chart
Chart Speed
7D/Rev
Chart Calibrated Radius
2.3" (approx. 59mm)
Chart Ranges
Programmable
Display, Operator Panels and Input
Display Type
3½ digit LCD
Status Indicator
RTC, Batch Status, Battery Status
Panel Keys
Front panel KB consisting of 3 keys for programming and
calibration
Analog Input
RTD PT-100
Sensor Type and Range
Refer to Table 1
Scan Rate
Continuous 1 reading per second
Memory
Memory Size
64KB
Data Storage
Up to 14 days at 5min Store Interval
Alarm Records
Yes (Going out of limit and coming back to limit is considered as
one alarm record)
Record for Door Open / Close
Yes
Mains Failure Record
Yes
Memory Type
Cyclical – Most recent data is always available
User Settable Parameters for Recording
Alarm Condition Occurrence Time
Delay
1 to 99 mins; user settable (through PC)
When the temperature remains out of limit for more than set
time then only the alarm condition is assumed.
Real Time Clock (RTC)
Settable from Keyboard in DD/MM/YY/HR/MN format
Door Open/Close
Input through Potential Free contact.
Communication
