6.2 OVERALL MECHANICAL DIMENSIONS:
Figure 4 Overall Mechanical Dimensions
Table 3 Overall Mechanical Dimensions
Overall Dimensions(approx.)
Dimensions L x W x D (mm)
232 x 205 x 117
Panel Cutout L X W (mm)
198 x 169
Bezel L x W (mm)
232 x 205
