G-Tek 27 Series User Manual

Page No. 7
**Refer to the back panel of recorder for exact rating.
Table 2 Chart type of Chart Recorder
Sr. No.
Range**
Speed
Size
Part No.
Part Description
21
0 to +100
24H
6”
304001
D60100
22
0 to +150
24H
6”
304002
D60150
23
0 to +200
24H
6”
304005
D60200
24
0 to +300
24H
6”
304008
D60300
25
-50 to +50
24H
6”
304016
D6-50+50
26
0 to +160 & -1 to 3
24H
6”
304004
D60160&-1+3
27
+90 to +140
4H
6”
305001
4H90140
28
0 to +100
7 Day
6”
307001
W60100
29
-50 to +50
7 Day
6”
307010
W6-50+50
30
+50 to -50
7 Day
6”
307009
W650-50
31
-100 to +50
7 Day
6”
307005
W6-100+50
32
+50 to -100
7 Day
6”
307008
W650-100
33
+40 to -10
7 Day
6”
307007
W640-10
34
0 to +50
7 Day
6”
307004
W6050
35
0 to +10
7 Day
6”
307012
W6010
36
+20 to -10 (PS)
7D
6”
308009
W620-10PS
37
+50 to -100 (PS)
7D
6”
308008
W650-100PS
39
+40 to -10 (PS)
7D
6”
308003
W640-10PS
40
-50 to + 50 (PS)
7D
6”
210042
W6-5050PS
50
Other Please Specify
** First value in the chart is at the center of the Chart.
** Chart range low and chart speed are fixed as per the order code.
# PS: Pressure Sensitive Chart
