Page No. 13
ELECTRICAL INSTALLATION
7.1 WIRING DIAGRAM FOR RECORDER
Refer the figure 6, to connect AC mains,12V DC Input, door switch input and sensor to the
recorder.
Figure 6 Back panel view with notation
RTD
connection
12VDC
battery
connection
Door switch
connection
LNE (Mains)
connection
