5.3 Regulating the rebate clearance
The factory setting of SECUREconnect F regarding the rebate clearance
is  -  mm. For increasing this value to  -  mm, it is possible to pull out
the restricting brackets on the side of the tappet contacts using a small
screwdriver. In doing so, the adhesive label "Hubverstellung der Kontakte"
(adjustment of contact travel) must be removed carefully and re-attached
afterwards. The tappet contacts now protrude  mm from the device.
Do not reinsert the restriction brackets with the rebate clearance set
to  -  mm !
If you wish to limit SECUREconnect F to a rebate clearance of  mm
again, press back the tappet contacts until stop and reinsert the restricting
brackets.
Do not adjust to  -  mm rebate clearance if the
clearance is smaller than  mm. This would increase
the strain on the contacts and reduce the service
life of the device.
ATTENTION
Reattach the adhesive label for protection !
