8.8.1 IO module inputs
Two IO or IO modules can be connected to SECUREconnect R via
terminals LA and LB.
Input and output parameters are preset in compliance with the BKS-NET
concept.
Input IO Device  Function
Input : terminal I, V Permanent OPEN (unlocking)
Input : Terminal I, V Close (locking)
Input : Terminal I, V Priority locking
Input : Terminal I, V Priority unlocking
Input IO Device  Function
Input : Terminal I, V Non-priority unlocking
Input : Terminal I, V -
Input : Terminal I, V Short-time OPEN
Input : Terminal I, V -
Input IO Function
Input : Terminal I, V Permanent OPEN (unlocking)
