Power and data transmission unit
Mounting und operating instructions
SECUREconnect 200
. | EE | Printed in Germany
EN
The mains cable is plugged in at the bottom side of SECUREconnect R
and must be fixed by all means with the attached cable tie to prevent it from
coming loose.
The borehole must be fitted with the enclosed rubber grommet to protect
the lead.
All edges touched by the mains cable must be unsharp and free of burrs.
If SECUREconnect is connected to AC V, a DC V (. A) voltage
for external devices will be available at terminals V and G.
7. Start-up
Please observe the mounting advice given in chapter !
Install SECUREconnect F in the door leaf and connect the electrical
lock according to the particular connection diagram.
Install SECUREconnect R in the door frame exactly on the opposite
side.
Ensure that the tappet contacts of SECUREconnect F exactly
coincide with the contact surfaces of SECUREconnect R as the door
closes (see also installation drawing --L).
Connect SECUREconnect R to the operating voltage supply’
(AC V or DC V).
Cables may be damaged when turning in the
fastening screws.
We recommend: Insert screw through device and fix
cable beside the screw with adhesive tape.
ATTENTION
