Explanation:
 Hz =  flashes per second
 Hz =  flashes per second
 Hz = LED . seconds on,  flash per second
. Hz = LED  second on
7.3 Functions with motor-driven locks
7.3.1 Short-time OPEN (short-term release)
If a potential-free contact connected to terminals  / V is actuated with
the door closed, SECUREconnect F receives the signal to release the
electrical lock and to retract the latch.
When the door is opened, the electrical lock will extend the latch again after
 s, so the door will be locked without delay as it is closed again.
If the door remains closed, the latchbolt will extend after  -  s (time
adjustable).
If a potential-free contact (gating pulse) connected to terminals  / V is
actuated permanently, the electrical lock remains open for the duration of
the signal.

When the door is opened, the electrical lock will extend the latch again
after  s.

When the door is closed again, the electrical lock will retract the latch.
Here it may happen that the extended latchbolt
hits the striker. In that case, please check the
locking status of the door.
ATTENTION
