Galil Motion Control DMC-40x0 Series User Manual

DMC-40x0 Command Reference NZ • 173
NZ
FUNCTION: Notch Zero
DESCRIPTION:
The NZ command sets the real part of the notch zero.
ARGUMENTS: NZ n,n,n,n,n,n,n,n or NZA=n where
n is ranges from 1 Hz to
1
16()⋅ TM
n = ? Returns the value of the Notch filter zero for the specified axis.
USAGE: DEFAULTS:
While Moving Yes Default Value 0.5
In a Program Yes Default Format 3.1
Command Line Yes
Controller Usage
ALL CONTROLLERS
OPERAND USAGE:
_NZn contains the value of the Notch filter zero for the specified axis.
RELATED COMMANDS:
1NB Notch Bandwidth
NF Notch Filter
EXAMPLES:
NZA = 10 Sets the real part of the notch pole to 10/2 Hz
Note: TM in seconds and defaults to .001
