Gallagher W810 v2 User Manual

3E2364WeighScaleW810v2UserManual

 Page31

SettingupaBluetoothport
TheWeighScaleW810v2hasinternalBluetooththatallowscommunication
withaBluetoothElectronicIDreader.YourElectronicIDreaderwillneedtobe
pairedwiththeWeighScale.
Note:TheBluetoothportmustbeconfiguredtoadeviceandnot"Unused"beforeit
willbediscoverableandabletobesearchedforbyotherdevices.

ToattachaGallagherHR3ReadertotheBluetoothport,completethefollowing
steps:
1. FromtheCommunicationsmenu,pressthe  buttontoselect
theBluetoothport.
2. Press and  ifrequired,todisplayEIDReader‐
Standard
.
3. Pressthe
 softkey.
4. Press
 todisplaytheMACaddressforthescale.

5. YouwillneedtoconfigureyourHR3readerwiththeScaleMACaddress.This
isusuallydonewiththeConfiguratorsoftwaresuppliedwithyourElectronic
IDreader.
6. WhenthedevicehaspairedtotheWeighScaleablueLEDlightwilldisplay
ontheWeighScalealongsidetheLCDscreens.TheBluetoothSettings
screenwillshowthedevicetypeandMACaddressofthedeviceconnected.
7. Press  tosavethesettingsandreturntotheSetupmenu.
