13FocalPoint™ Gateway Installation & Operation Manual - P/N: 52649:Rev: B3 2/11/10
Section 2 FPT Gateway Installation
2.1 Required Equipment
The FPT Gateway requires the following:
FPT Gateway Assembly (P/N: FPT-GATE)
The following are shipped with the FPT Gateway:
• FocalPoint™ Gateway PC board (P/N: 46224).
• PNET-1 surge suppressor (P/N: PNET-1).
• CAT5 cable (P/N: 75644) - provides Ethernet connection from gateway PC board to PNET-1
surge suppressor.
• DB9 to leads cable (P/N: 75267) - serial cable that is used as to connect the gateway PC board
to an E3 panel.
• DB9 to RJ-11 cable (P/N: 6100-0077) - provides serial cable to DB9 connector connection.
• Serial Cable (P/N: 6100-0076)- serial cable that is used as to connect the gateway PC board to
a 7100/7200 panels.
• UL Requires the 7200 and E3 panels to have a two line DACT in addition to the gateway for
event reporting.
• Cabinet (P/N: FPT-BA) which includes various screws, hex nuts, star washer, and door lock
key.
• “.010 Formex GK-BK-10 (BLK). UL 94 ZTM-0.”- need to place this insulator in the bottom
of the cabinet in order to meet ULC S527-99 spacing requirements.
• FocalPoint Gateway Config Tool.
• FPT Gateway Manual.
Network Components
• RJ45 to RJ45 standard Ethernet network cable - Network connection to PNET-1 surge
suppressor (supplied by customer).
• Gamewell/FCI Panel (sold separately, Section 1.2.3 on page 10).
• Gamewell Router (P/N: GWPTP-NC) - sold separately.
• FocalPoint™ Workstation computer with software application installed (sold separately).
Customer Supplied Equipment
• A regulated, UL 1481 listed, power limited, battery backed, +24 VDC power supply.
2.2 Installation Overview
• “Cabinet Installation” on page 15.
• “Hardware Installation” on page 16.
!
WARNING: Installation
Improper installation, maintenance, and lack of routine testing could result in system malfunction.
!
CAUTION:
Different sources of power are used in conjunction with the FPT Gateway product
. Disconnect all
sources of power before servicing
. This device and associated equipment may be damaged by removing
and/or inserting cards, modules or interconnecting cables while this unit is powered
. This damage may
adversely affect the operation of this unit, but its effect may not be readily apparent.
