FPT Gateway Overview Product Description
8 FocalPoint™ Gateway Installation & Operation Manual - P/N: 52649:Rev: B3 2/11/10
Figure 1.2 Advanced FPT Gateway Network - FCI
90.23 effective October 1, 2005
1.1.1 About Workstation Ethernet Network Installations
The FocalPoint™ Workstation is a Proprietary Supervising Station that has a supervised client
server architecture that communicates over IP networks. The Ethernet network can be a shared
bandwidth system that operates over topologies such as an intranet, the Internet, or a frame relay
system.
If the Workstation or gateway is sharing on-premises communications equipment, the shared
equipment shall be “listed for the purpose”. “Listed for the purpose” has been formally interpreted
by NFPA (Formal Interpretation 72-99-1) for equipment on packet switched networks as being
listed to the requirements applicable to general purpose communications network equipment.
For ULC applications, the Internet cannot be used for either primary or ancillary functionality.
Gateway
Workstation
Other Technologies
LAN/WAN/Internet/Intranet
7200
E3
Gateway
Workstation
NOTE: Turn on the remote annunciator supervision on the router to which the gateway connects
for the networked Gamewell panels.
NOTICE TO USERS, INSTALLERS, AUTHORIES HAVING JURISDICTION, AND OTHER INVOLVED PARITES
This product incorporates field-programmable software. In order for the product to comply with the requirements in the Standard
for Control Units and Accessories for Fire Alarm Systems, UL 864, certain programming features or options must be limited to
specific values or not used at all as indicated below.
Program feature or option Permited in UL 864 (Y/N) Possible Settings Settings permitted in UL 864
Remote resetting and
silencing of a fire alarm
control unit from other than
the protected premises (ref:
NFPA 72-2007 6.8.2.8)
No Security Levels
• Administrator
• User with Point Control
• User with Client Control
• Default User
