13-21-602 Page 37

COMPRESSOR CAPACITY CONTROL - TURN VALVE UNITS ONLY

The capacity of the compressor is controlled by the action of the turn valve and the compressor inlet

valve.

The turn valve controls compressor delivery to match demands of 40% to 100% of the compressor’s

maximum capacity. The inlet valve throttles to control compressor delivery to match demands of 0% to

40% of the compressors maximum capacity.

Example with normal setting of 100 PSIG:

Compressor Delivery

Capacity

Inlet Valve Position Turn Valve Position Discharge Manifold

Pressure (psi)

Full

Open

Closed

100

70%

Open

50% Open

100

40%

Open

Full Open

100

30%

Closing

Full Open

103

20%

Closing

Full Open

103

Closed

Full Open

103
