Garmin G1000 Pilot’s Guide for the Piper PA-32 Saratoga
190-02692-00 Rev. A232
FLIGHT MANAGEMENT
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICESINDEX
Entering/designating or modifying an altitude constraint:
1) Press the FPL Key for the MFD to display the FPL – ACTIVE FLIGHT PLAN Page.
2) Push the FMS Knob, and turn to highlight the desired waypoint altitude constraint.
3) Turn the small FMS Knob and enter an altitude constraint value using the FMS Knobs.
4) Press the ENT Key to accept the constraint. If the selected waypoint is an aerodrome without a runway selected,
an additional choice is displayed. Turn the small FMS Knob to choose MSL or AGL, and press the ENT Key to
accept the altitude.
5) Press the ENT Key to accept the altitude constraint.
Removing/undesignating an altitude constraint:
1) Press the FPL Key for the MFD to display the FPL – ACTIVE FLIGHT PLAN Page.
2) Push the FMS Knob, and turn to highlight the desired waypoint altitude constraint.
3) Press the CLR Key. A ‘Remove VNV altitude?’ confirmation window is displayed.
4) Select OK and press the ENT Key.
Reverting a manually entered altitude constraint back to the navigation database value:
1) Press the FPL Key for the MFD to display the FPL – ACTIVE FLIGHT PLAN Page.
2) Push the FMS Knob, and turn to highlight the desired waypoint altitude constraint.
3) Press the CLR Key. A ‘Remove or Revert to published VNV altitude of nnnnnFT?’ confirmation window is
displayed.
4) Select ‘Revert’ and press the ENT Key. The altitude is changed to the navigation database value.
