9ENG8008 GFM436 User Manual
Before you can start storing or logging readings you need to create a sample point, essentially a name or location
information for your log. This is done using the Sample Point Setup function.
12.3 Sample Point Setup
A sample point is the name given to the point at which the instrument draws a sample of gas from a main gas pipe.
As there is a great number of different sample points a customer may use, users may set up ID tags on the
instruments to symbolise particular sample points (or to symbolise anything the customer desires). Instructions on
setting up these sample point IDs are found below:
On the Gas Readings display, using the soft keys, open the menu and select “Sample point setup” using the OK key.
This opens the ID selection table. To understand the structure behind the ID numbers, see the chapter on Data
Storage ID Structure.
To edit the name of an ID, navigate to the desired cell (either one to be edited or a blank cell for a new entry) and
press OK. Use the arrows and OK key to enter the desired name for the ID selected. Then press the left soft key to
“Accept”.
