GatesAir Intraplex PTR-255 - AES;EBU Consumer Format

GatesAir PTR-255 Program Audio Codec Module
Intraplex Products Issue 2.1, February 2006
8
2.3.1.1 AES/EBU Consumer Format
Model:
PTR-255 set to consumer mode
Receiver classification:
B2
Transmitter classification:
Standard
Key: TX: N = not transmitted; Y = transmitted
RX: N = not recognized; Y = recognized; S = recognized and passed through
Table 2-1
AES/EBU Channel Status (C) Data: Consumer Format
Byte
Bit
Function
RX
TX
Remarks
0
0
0 Consumer use
1 Prof use
Y
Y
Y
Y
RX: responds to either format
TX: can be set to either format
1
0 audio
1 non audio
N
N
Y
N
2 copy prohibit
0 copy prohibited
1 copy permitted
N
N
N
Y
3-5 emphasis
000 two channels without
emphasis
100 two channels with
50/15uS emphasis
Y
Y
Y
N
RX: detects and removes
emphasis before transmission
TX: always sends without
emphasis
6-7 category
code
00 mode 0
N
Y
1
0-6 channel
mode
000000 2 channel, general
format
N
Y
7
L-bit
0 digital copy prohibited
1 digital copy permitted
N
N
N
Y
2
0-3 source
number
0000 don’t care
N
Y
4-7 channel
number
0000 don’t care
N
Y
TX Validity bit handling:
 When in 2 channel mode, any unmitigated A channel error mutes the A channel
outgoing audio and sets the A channel validity bit to 1; any unmitigated B channel
error mutes the B channel outgoing audio and sets the B channel validity bit to 1.
 When in 1 channel mode, any unmitigated A channel error mutes the A channel
outgoing audio and sets the A channel validity bit to 1. The B channel validity bit is
always set to 0.
